سوکت CAT5E UTP - کانکتور نری RJ45 بسته 100 عددی
Features:
Brand:CNCOB
interface:RJ45
Model:super five non-shielded CAT5E UTP)
function:integrated network cabling, network cable interface
Applicable wire: for single strand core diameter 00.96-01.02
diameter:single conductor copper 24 + 26AWG
material:new environmentally friendly PC material .
Electrical characteristics:250 V AC. Maximum 2A Withstand Voltage Volts
Voltage Test:Less than 0.5A 1000 V DC / min
Insulation Resistance 1000 Volts DC / min, Greater than 500MΩ
Contact Resistance:Less than 20mΩ Millio Rally
Test Cable to Socket Tension Strength At least 20 lb
Durability Test :Mating Test 2000 Times more than the new level of raw
materials PC material. Fire rating 94V2
Gold material Phosphor bronze High strength copper alloy
Plating material 100microinches Nickel plated and gold plated
Operating temperature -40 ℃ ~ +125C etc. 2 C5
