این برد توسعه بر پایه چیپ STM8S103F3P6 طراحی شده است که یکی از سری چیپ های هشت بیتی خانواده ARM میباشد.
این آی سی ، با 3.3V تغدیه میشود و دارای ارتباطات I2C ، SPI و سریال میباشد، همچینین 8k بایت فضای فلش، 1k بایت رم و 640 بایت حافظه EEPROM دارد.
در برد توسعه STM8S103F3P6 با تغذیه micro USB، یک رگولاتور با خروجی 3.3 ولت تعبیه شده است تا بتوان از طریق میکرو USB و کامپیوتر و همچنین Vin (بین 4.5V تا 15V) آن را تغذیه کرد.
قابل ذکر است که فاصله بین پین های ماژول استاندارد 2.54mm میباشد که به راحتی میتوان آن را روی برد برد سوار کرد.
Description:
The STM8S103F3P6 access line 8-bit microcontrollers offer 8 Kbyte Flash program memory, plus integrated true data EEPROM.
The STM8S microcontroller family reference manual (RM0016) refers to devices in this family as low-density. They provide the following benefits: performance, robustness, and reduced system cost.
Device performance and robustness are ensured by advanced core and peripherals made in a state-of-the art technology, a 16 MHz clock frequency, robust I/Os, independent watchdogs with separate clock source, and a clock security system.
The system cost is reduced thanks to an integrated true data EEPROM for up to 300 k write/erase cycles and a high system integration level with internal clock oscillators, watchdog and brown-out reset.
This IC is powered by 3.3V and has I2C, SPI and serial communication, it also has 8k bytes of flash space, 1k bytes of RAM and 640 bytes of EEPROM memory.
In the STM8S103F3P6 Development Board, a regulator with 3.3V output is built in so that it can be powered via micro USB and PC as well as Vin (between 4.5V and 15V).
It should be noted that the distance between the module pins is 2.54mm standard, which can be easily mounted on the board.
Application:
Digital circuits
educational
laboratory
Specifications:
Main chip: STM8S103F3P6
Base number: 26
Supply voltage: 4.5Vdc ~ 15Vdc
Port: micro USB (power only)
Communication: SPI, I2C, UART
GPIO pins: 16
Flash: 8Kb
RAM: 1Kb
EEPROM: 640b
