Descriptions:
Strengthen your antenna connection with the SMAM-SMAF connector/adapter/plug. With 50 ohm impedance and full ROHS compliance, this connector offers exceptional signal performance while meeting industry standards for environmental safety.
The carefully designed female signal pin seamlessly aligns with the main SMA type antenna, ensuring a safe and reliable connection. This adapter serves as the perfect solution to convert RP-SMA board/module to SMA type and enables seamless compatibility with the normal SMA part of your antenna.
Application:
Allows you to connect antennas and cables directly to the modem with standard SMA connectors.
SMA type connector is used to connect coaxial cable with 50 Ohm wave impedance.
Specifications:
Machined brass construction
Long-lasting cycles: 500 cycles
Type: SMA female to RP-SMA male adapter
Insulation material: Teflon
Material: brass with nickel coating.
Color: silver, gold.
Socket: Beryllium bronze with gold plating
Type 0 seal: 6146 silicone rubber
Technical features:
Temperature range: -65~+165°C (PE cable -40~+85°C).
Impedance: 50Ω
Frequency range: DC-6 GHz.
Working voltage: 335 volts maximum
Dielectric strength: 1000V rms
Contact resistance: internal contact less than 5mΩ - external contact less than 2mΩ
Insulation resistance more than 5000mΩ
Insertion loss less than 0.15dB/60GHz
