ماژول گیرنده وایرلس RXB6 دارای فرکانس 433Mhz

RXB6-433MHZ

4857-119-7692

89,790 تومان
کالا موجود است
موجودی انبار : 9 عدد


خرید کالا


علاقه مندان : -
وضعیت : فعال

تعداد مرجوعی : 1
دنبال کنندگان : -

قدمت : 5 سال و 3 ماه و 7 روز
وزن : 3 گرم

کل فروش : 81 عدد
تعداد سفارش ها : 31 سفارش

هنوز هیچ رایی ثبت نشده است
ماژول گیرنده وایرلس RXB6 دارای فرکانس 433Mhz

 ماژول های فرستنده و گیرنده بی سیم یکی از مهم ترین ابزارها در طراحی ریموت کنترلها به شمار می روند. به کمک ماژول های فرستنده گیرنده بی سیم برد کوتاه شما می توانید وسایل برقی را کنترل کرده یا به تبادل داده با میکروکنترلرها بپردازید. ماژول گیرنده RXB6 ، یک ماژول فوق العاده کلیدی و کاربردی است و در فرکانس 433 مگاهرتز کار می کند و می تواند با ریموتهایی در این فرکانس، سازگار شود. به عبارت دیگر به کمک این ماژول و ریموت فرستنده، می توانید یک ریموت کنترل برای وسایل مختلف نظیر درهای برقی، کرکره برقی و... بسازید.


کاربرد ماژول گیرنده وایرلس مدل RXB6-433:

  1. سوئیچ درب، ریموت کنترل
  2. هشدار امنیتی بی سیم
  3. کنترل صنعتی بی سیم
  4. انتقال داده بی سیم

مشخصات ماژول گیرنده وایرلس مدل RXB6-433:

  1. مدل: RXB61
  2. فرکانس: 433 مگاهرتز
  3. مدولاسیون: ASK
  4. حساسیت: 115dBm-
  5. دمای کاری: 30- تا 85+ درجه سانتی گراد
  6. ولتاژ: 3.5-5.5 ولت DC
  7. سازگار با اکثر فرستنده‌ها (ASK/OOK)
  8. جریان کاری: 5 میلی آمپر
  9. دارای امواج RF بسیار پایین
  10. اندازه: 30.5x7.5x5 میلی متر

Description:
The RXB6 is based on a Superheterodyne design with PLL and Automatic Gain Control. The new design is less immune to noise than our our standard TX/RX pair. The RXB6 pair is a great choice for controlling devices remotely.
This wireless high-frequency receiver module RXB6 is through Rely R&D team assembled many years of experience to develop this high sensitivity OOK receive module lost cost, high stable also can provide the best RF solution in the market.
Highly suitable for industry control or bad place for use ,strong anti-jamming Built-in automatic gain circuit(AGC),it will automatically change front-end LNA gain among received signal strength also makes signal output will not be strong or weak signals which caused by phase distortion so that it can rise higher sensitivity To receive the local oscillation circuit for the PLL lock loop design, no offset and stability is high.

Application:
car remote control door switch (RKE)
remote control door opener
wireless security alarm
remote control curtain machine
wireless industrial controller
wireless data transmission

Features:
receiving sensitivity of -112dBm;

Operating Frequency: 433.92 MHz;
power supply voltage input range: 3V-5.5V;
low power consumption, 3.3V @ 433.92MHz,
enabling the power consumption mode can be done 50nA;
with RSSI signal strength analog level output;
good selectivity and stray radiation suppression capability, easy to pass CE/Fcc international certification;
good local oscillator radiation suppression capability, can work with multiple receiving modules (ie, single-issue and over-receipt) and will not interfere with each other, and use together does not affect the receiving distance.
Temperature range: -40-85 °C Works even in harsh ambient temperatures.
